MAIN TECHNICAL FEATURES
Advanced technology
Multiple-unit Servo Synchronous Control System
High reliability
Excellent manufacturing quality and advanced supporting facilities
Good controllability
High automation level, simple operation
High control precision
The computer automatically controls elongation, temperature, pressure, and moisture regain
Good manufacturability
Dual-sizing tank, high-pressure and high-precision control
Energy saving
All cylinder drying, energy-saving and efficient
High cost-performance
Reaching the advanced level of contemporary interational standards, with reasonable prices and excellent economic benefits
Table of Main Technical Parameters
| Item | Main Specifications | |
| Width (mm) | 2000,2400,2800,3200,3600 | |
| Winding Diameter of Weaving Beam (mm) | Φ800,Φ1250 | |
| Quantity of Drying Cylinder | 8,10,12,14,16 | |
| Quantity of warping beam | 12,16,20,24,28,32 | |
| Max.Dia of warping beam (mm) | Φ800,Φ1250 | |
| Speed (m/min) | 1-160m/min | |
| Pre-Squeezing Pressure (Mpa) | 0-0.5mpa | |
| High-Squeezing Pressure | Max. Pre-pressure: 0-0.6mpa | |
| Total Power (kw) | Max. High-pressure: 30-60KW | |
| Maximum winding tension | 1000Kg | |
| Sizing structure | Double-dip, Double-nip, Six-roller Type; Single-dip, Double-nip, Five-roller Type | |
| Drying chamber structure | Horizontal type | Elevated type |
REMOTE DIAGNOSING SYSTEM
Wh the adoption of a remcte dagnosing sstem, the folowing addtonal teatures are avalable tor user salection and configuration.
Remcte dagnoding and managemert of mulitple szing machines alow for more conerient trading of eqipment uage satus and proces management.
Storable process tormula parameters ticitatng process management partculiarly sutable for testing new wariedies aind processes as wel as reglicatngprocesses for repeated varieties, saving time and reducing energy consumption
HMl with muliple-language dieplarying is globaly available for users
Connedting with our alter-sales service engineers through telecommunication module to erioy faster service.
