Yarn Sizing Machine

All-Round Player for Many Yarn Types

This yarn sizing machine is a multi-purpose tool. It works with staple yarns and filaments. The market today changes fast. Small batches and many types are normal. You may work with cotton, linen, wool, man-made fibers, or blends. Buying a different machine for each type costs too much. So we built this machine to be an all-round player. It fits different fiber needs and gives you a quality sized beam. Our customers often ask if one machine can really handle so many types. We tell them yes, and it does it well. This is the Yarn Sizing Machine that saves you money.

This machine has a strong frame made from steel plates. Key parts use wear-resistant ceramic and stainless steel. The size box is 304 stainless steel. It uses a double-dip and double-squeeze system. The squeeze roller uses imported polyurethane. Its hardness is Shore 82±2. The pressure can be set from 0 to 35 kN. The size temperature is controlled to ±1℃. An auto system circulates and filters the size. The guide rollers have a wear-resistant coating. The surface is smooth at Ra 0.1 μm. This cuts down yarn fuzz. The tension system uses a servo motor and runs on its own. The accuracy is ±0.8 cN. This Yarn Sizing Machine handles cotton, man-made fibers, and blends with ease.

This machine runs at a wide speed range. You can set it from 30 to 160 meters per minute. The beam can be up to 800 mm. One client in Nantong makes many types of blends. They said changing products on this machine is very easy. An online system checks the size viscosity. The accuracy is ±0.5 seconds. The size pickup is even at over 96%. The machine has an auto beam change system. The screen is 15 inches. You can store 1000 settings inside. This supports quick product changes. The beam is straight, with an error under 0.1mm over 1 meter. The winding density error is under 2%. This machine meets ISO 11111-1:2016 and CE standards. It also meets ISO 5239. At Jiangsu Global Jingtian, we give you one machine for many uses. This Yarn Sizing Machine cuts your equipment cost and helps you respond to market fast.
